Flotation Implement Tires for Agriculture | High-Durability I-1 & I-3 Tires by APEXWAY

DESIGN BYIBEST

Flotation Implement Tire

Vehicle For:
Sprayers (trailed) / Fertilizer / Lime Spreaders (trailed) / Implement Trailers / Utility Wagons / General-Purpose Farm Trailers / Silage / Forage Trailers / Forage Wagons / Manure (muck) Spreaders / Slurry Tankers Beet / Root-Crop Trailers / Carts / Seeders / Seed Drills (trailed) / Irrigation Hose Reels (trailed) / Bale Wrappers / Turntables

E-CATALOGUE

DOWNLOAD

HOME/ PRODUCTS/ Agricultural Tire/ Flotation Implement Tire

Agricultural Tire / Flotation Implement Tire

CLOSE BOX

Size

Pattern

P.R.

TRA

O.D. (inch/mm)

S.W. (inch/mm)

Rim Diameter (inch)

CLEAR SEND

SPECIFICATION

PATTERN

SPECIFICATION

Size	Pattern	P.R.	Load/Speed	Type	TRA	Rim Width (inch)	O.D. (inch/mm)	S.W. (inch/mm)	Inflation Pressure (PSI/bar/kPa)
10.0/75-15.3	C1C0006	8	119A8	TT/TL	I-1	9.00	29.9/760	10.4/264	45.0/3.1/310
10.0/75-15.3	C1C0006	10	123A8	TT/TL	I-1	9.00	29.9/760	10.4/264	56.6/3.9/390
10.0/75-15.3	C1C0006	12	126A8	TT/TL	I-1	9.00	29.9/760	10.4/264	68.2/4.7/470
10.0/75-15.3	C1C0006	14	130A8	TT/TL	I-1	9.00	29.9/760	10.4/264	79.8/5.5/550
11.5/80-15.3	C1C0006	10	131A8	TT/TL	I-1	9.00	33.3/845	11.4/290	49.3/3.4/340
11.5/80-15.3	C1C0006	12	135A8	TT/TL	I-1	9.00	33.3/845	11.4/290	59.5/4.1/410
11.5/80-15.3	C1C0006	14	139A8	TT/TL	I-1	9.00	33.3/845	11.4/290	68.9/4.75/475
11.5/80-15.3	C1C0006	16	141A8	TT/TL	I-1	9.00	33.3/845	11.4/290	78.3/5.4/540
12.5/80-15.3	C1C0006	12	142A8	TT/TL	I-1	9.00	38.0/965	12.1/308	53.7/3.7/370
12.5/80-15.3	C1C0006	14	146A8	TT/TL	I-1	9.00	38.0/965	12.1/308	62.4/4.3/430
400/60-15.5	C1C0006	14	145A8	TT/TL	I-1	13.00	34.3/870	15.9/404	52.2/3.6/360
400/60-15.5	C1C0009	14	145A8	TT/TL	I-1	13.00	34.3/870	15.9/404	52.2/3.6/360
400/60-15.5	C1C0028	14	145A8	TT/TL	I-1	13.00	34.3/870	15.9/404	52.2/3.6/360
400/60-15.5	C1C0006	16	149A8	TT/TL	I-1	13.00	34.3/870	15.9/404	58.0/4.0/400
400/60-15.5	C1C0009	16	149A8	TT/TL	I-1	13.00	34.3/870	15.9/404	58.0/4.0/400
400/60-15.5	C1C0028	16	149A8	TT/TL	I-1	13.00	34.3/870	15.9/404	58.0/4.0/400
400/60-15.5	C1C0014	14	145A8	TT/TL	I-3	13.00	34.3/870	15.9/404	52.2/3.6/360
400/60-15.5	C1C0014	16	149A8	TT/TL	I-3	13.00	34.3/870	15.9/404	58.0/4.0/400
15.0/55-17	C1C0018	10	134A8	TL	I-1	13.00	33.5/850	15.4/391	37.7/2.6/260
15.0/55-17	C1C0018	12	138A8	TL	I-1	13.00	33.5/850	15.4/391	45.0/3.1/310
15.0/55-17	C1C0018	14	141A8	TL	I-1	13.00	33.5/850	15.4/391	52.2/3.6/360
15.0/55-17	C1C0018	16	143A8	TL	I-1	13.00	33.5/850	15.4/391	59.5/4.1/410
19.0/45-17	C1C0018	14	147A8	TL	I-1	16.00	34.1/866	19.3/491	45.0/3.1/310
19.0/45-17	C1C0018	16	149A8	TL	I-1	16.00	34.1/866	19.3/491	49.3/3.4/340
400/60-22.5	C1C0024	16	152A8	TL	I-3	13.00	39.8/1012	15.9/404	58.0/4.0/400
600/50-22.5	C1C0013	16	168A8	TL	I-3	20.00	46.1/1172	24.1/611	46.4/3.2/320
600/50-22.5	C1C0024	16	168A8	TL	I-3	20.00	46.1/1172	24.1/611	46.4/3.2/320
650/50-22.5	C1C0013	16	160A8	TL	I-3	20.00	48.5/1232	25.4/645	40.6/2.8/280
710/40-22.5	C1C0013	16	165A8	TL	I-3	24.00	46.1/1172	28.6/727	37.7/2.6/260
600/55-26.5	C1C0013	16	166A8	TL	I-3	20.00	52.4/1330	23.4/595	34.8/2.4/240
650/55-26.5	C1C0013	16	167A8	TL	I-3	22.00	52.8/1340	25.4/645	34.8/2.4/240
800/45-26.5	C1C0013	16	172A8	TL	I-3	28.00	53.1/1350	32.3/820	34.8/2.4/240
