SPECIFICATION
PATTERN
SPECIFICATION
| Inquiry | Size | Pattern | Hole No. | Bolt of Dia. (mm) | P.C.D. | Center Hole Dia (mm) | Offset | Offset to Flange | Disc Thickness (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 6.50F-10 | 3 Piece | 8H | Φ16 | Φ170 | Φ125 | +48±1.5 | 130.5 | 14 | |
| 6.50F-10 | 3 Piece | 6H | Φ18 | Φ180 | Φ150 | -5.5±1.5 | 71 | 12 | |
| 6.50F-10 | 3 Piece | 6H | Φ18 | Φ140 | Φ105 | 0 | 103 | 10 | |
| 4.50-15 | 3 Piece | 8H | Φ27 | Φ190 | Φ145 | 0 | 150 | 8 | |
| 5.50F-15 | 3 Piece | 6H | Φ15.7 | Φ153 | Φ118 | +42±1.5 | 99 | 10 | |
| 5.50F-15 | 3 Piece | 6H | Φ15 | Φ153 | Φ118 | 0 | 70 | 10 | |
| 5.50F-15 | 3 Piece | 6H | Φ15.7 | Φ153 | Φ118 | +42±1.5 | 99 | 10 | |
| 5.50F-15 | 3 Piece | 6H | Φ15 | Φ153 | Φ118 | 0 | 70 | 10 | |
| 5.50F-15 | 3 Piece | 6H | Φ15.7 | Φ153 | Φ118 | +42±1.5 | 99 | 10 | |
| 5.50F-15 | 3 Piece | 6H | Φ15 | Φ153 | Φ118 | 0 | 70 | 10 | |
| 6.50T-15 | 3 Piece | 8H | Φ32 | Φ290 | Φ240 | +123±1.5 | 212 | 12 | |
| 6.50T-15 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -26±1.5 | 50.5 | 12 | |
| 6.50T-15 | 3 Piece | 6H | Φ32 | Φ250 | Φ203 | +70.5±1.5 | 158.5 | 12 | |
| 6.50T-15 | 3 Piece | 8H | Φ32 | Φ290 | Φ240 | +123±1.5 | 212 | 12 | |
| 6.50T-15 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -26±1.5 | 50.5 | 12 | |
| 6.50T-15 | 3 Piece | 6H | Φ32 | Φ250 | Φ203 | +70.5±1.5 | 158.5 | 12 | |
| 7.00T-15 | 3 Piece | 6H | Φ31 | Φ222 | Φ370 | +30±1.5 | 125 | 12 | |
| 7.00T-15 | 3 Piece | 6H | Φ26 | Φ210 | Φ165 | 0 | 105 | 12 | |
| 7.00T-15 | 3 Piece | 6H | Φ16 | Φ152.4 | Φ118 | -33 | 51.5 | 12 | |
| 7.00T-15 | 3 Piece | 6H | Φ31 | Φ222 | Φ370 | +30±1.5 | 125 | 12 | |
| 7.00T-15 | 3 Piece | 6H | Φ26 | Φ210 | Φ165 | 0 | 105 | 12 | |
| 7.00T-15 | 3 Piece | 6H | Φ16 | Φ152.4 | Φ118 | -33 | 51.5 | 12 | |
| 8.00V-15 | 3 Piece | 8H | Φ26 | Φ275 | Φ315 | -79±1.5 | 0 | 16 | |
| 8.00V-15 | 3 Piece | 6H | Φ32 | Φ260 | Φ200 | +60±1.5 | 161.5 | 16 | |
| 8.50-15 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ152.4 | 0 | 109 | 12 | |
| 8.50-15 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ152.4 | 0 | 109 | 12 | |
| 9.75-15 | 3 Piece | 10H | Φ24 | Φ225 | Φ176 | 0 | 135 | 14 | |
| 9.75-15 | 3 Piece | 6H | Φ22 | Φ205 | Φ161 | 0 | 124 | 12 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | -18.7±1.5 | 51 | 12 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.3 | Φ204 | Φ153 | +24±1.5 | 105 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -6.2±1.5 | 63.5 | 12 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +24±1.5 | 100.2 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17 | Φ203 | Φ153 | -12.7±1.5 | 58.3 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ16 | Φ203 | Φ153 | +24±1.5 | 105 | 10 | |
| 6.00G-16 | 3 Piece | 6H | Φ21.5 | Φ170 | Φ120 | +22±1.5 | 104 | 10 | |
| 6.00G-16 | 3 Piece | 6H | Φ15.7 | Φ153 | Φ118 | +25.4±1.5 | 101.6 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | -18.7±1.5 | 51 | 12 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.3 | Φ204 | Φ153 | +24±1.5 | 105 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -6.2±1.5 | 63.5 | 12 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +24±1.5 | 100.2 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17 | Φ203 | Φ153 | -12.7±1.5 | 58.3 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ16 | Φ203 | Φ153 | +24±1.5 | 105 | 10 | |
| 6.00G-16 | 3 Piece | 6H | Φ21.5 | Φ170 | Φ120 | +22±1.5 | 104 | 10 | |
| 6.00G-16 | 3 Piece | 6H | Φ15.7 | Φ153 | Φ118 | +25.4±1.5 | 101.6 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | -18.7±1.5 | 51 | 12 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.3 | Φ204 | Φ153 | +24±1.5 | 105 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -6.2±1.5 | 63.5 | 12 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +24±1.5 | 100.2 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17 | Φ203 | Φ153 | -12.7±1.5 | 58.3 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ16 | Φ203 | Φ153 | +24±1.5 | 105 | 10 | |
| 6.00G-16 | 3 Piece | 6H | Φ21.5 | Φ170 | Φ120 | +22±1.5 | 104 | 10 | |
| 6.00G-16 | 3 Piece | 6H | Φ15.7 | Φ153 | Φ118 | +25.4±1.5 | 101.6 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | -18.7±1.5 | 51 | 12 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.3 | Φ204 | Φ153 | +24±1.5 | 105 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -6.2±1.5 | 63.5 | 12 | |
| 6.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +24±1.5 | 100.2 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ17 | Φ203 | Φ153 | -12.7±1.5 | 58.3 | 10 | |
| 6.00G-16 | 3 Piece | 8H | Φ16 | Φ203 | Φ153 | +24±1.5 | 105 | 10 | |
| 6.00G-16 | 3 Piece | 6H | Φ21.5 | Φ170 | Φ120 | +22±1.5 | 104 | 10 | |
| 6.00G-16 | 3 Piece | 6H | Φ15.7 | Φ153 | Φ118 | +25.4±1.5 | 101.6 | 10 | |
| 7.00T-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -25.4±1.5 | 116 | 12 | |
| 8.00G-16 | 3 Piece | 9H | Φ13.5 | Φ215 | Φ190.2 | +8.3±1.5 | 102.7 | 16 | |
| 8.00G-16 | 3 Piece | 8H | Φ21.5 | Φ275 | Φ221 | +26±1.5 | 127.6 | 10 | |
| 8.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +45±1.5 | 157 | 10 | |
| 8.00G-16 | 3 Piece | 8H | Φ15.7 | Φ273 | Φ229 | +45.9±1.5 | 147.5 | 10 | |
| 8.00G-16 | 3 Piece | 9H | Φ13.5 | Φ215 | Φ190.2 | +8.3±1.5 | 102.7 | 16 | |
| 8.00G-16 | 3 Piece | 8H | Φ21.5 | Φ275 | Φ221 | +26±1.5 | 127.6 | 10 | |
| 8.00G-16 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +45±1.5 | 157 | 10 | |
| 8.00G-16 | 3 Piece | 8H | Φ15.7 | Φ273 | Φ229 | +45.9±1.5 | 147.5 | 10 | |
| 11.25G-16 | 3 Piece | 8H | Φ17 | Φ203.2 | Φ153 | 0 | 143 | 12 | |
| 11.25G-16 | 3 Piece | 8H | Φ17 | Φ203.2 | Φ153 | 0 | 143 | 12 | |
| 7.00T-18 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ152.4 | +25.4±1.5 | 121.4 | 12 | |
| 7.00T-18 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ152.4 | +25.4±1.5 | 121.4 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ18 | Φ200 | Φ153 | -7±1.5 | 75 | 14 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +19±1.5 | 114 | 10 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +18±1.5 | 114 | 10 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -13±1.5 | 71 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +29±1.5 | 118 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +20±1.5 | 116 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ18 | Φ200 | Φ153 | -7±1.5 | 75 | 14 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +18±1.5 | 114 | 10 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +19±1.5 | 114 | 10 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +20±1.5 | 116 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -13±1.5 | 71 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +29±1.5 | 118 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ18 | Φ200 | Φ153 | -7±1.5 | 75 | 14 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +19±1.5 | 114 | 10 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +18±1.5 | 114 | 10 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -13±1.5 | 71 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +29±1.5 | 118 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +20±1.5 | 116 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ18 | Φ200 | Φ153 | -7±1.5 | 75 | 14 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +19±1.5 | 114 | 10 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +18±1.5 | 114 | 10 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -13±1.5 | 71 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +29±1.5 | 118 | 12 | |
| 7.00T-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +20±1.5 | 116 | 12 | |
| 7.50V-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +19±1.5 | 114.25 | 12 | |
| 7.50V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +23±1.5 | 125.6 | 10 | |
| 7.50V-20 | 3 Piece | 8H | Φ15 | Φ273 | Φ229 | +23±1.5 | 125.6 | 12 | |
| 8.00V-20 | 3 Piece | 12H | Φ26 | Φ381 | Φ325 | +137±1.5 | 238.6 | 14 | |
| 8.00V-20 | 3 Piece | 10H | Φ27 | Φ335 | Φ281 | +162±1.5 | 271 | 13 | |
| 8.00V-20 | 3 Piece | 8H | Φ22 | Φ275 | Φ221 | +15±1.5 | 124 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -84.5±1.5 | 13 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -82.6±1.5 | 0 | 14 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +4.5±1.5 | 106 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +23±1.5 | 124.6 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | 0 | 101.6 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ20.6 | Φ203.2 | Φ152.4 | +38.1±1.5 | 139.7 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ15.7 | Φ273.05 | Φ228.6 | +38.1±1.5 | 139.7 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ15 | Φ273.1 | Φ230 | -4±1.5 | 93.6 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ15 | Φ273 | Φ230 | -4±1.5 | 95.1 | 10 | |
| 8.00V-20 | 3 Piece | 5H | Φ21.5 | Φ335 | Φ291 | +36±1.5 | 137.5 | 12 | |
| 8.00V-20 | 3 Piece | 12H | Φ26 | Φ381 | Φ325 | +137±1.5 | 238.6 | 14 | |
| 8.00V-20 | 3 Piece | 10H | Φ27 | Φ335 | Φ281 | +162±1.5 | 271 | 13 | |
| 8.00V-20 | 3 Piece | 8H | Φ22 | Φ275 | Φ221 | +15±1.5 | 124 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ20.6 | Φ203.2 | Φ152.4 | +38.1±1.5 | 139.7 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +4.5±1.5 | 106 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -84.5±1.5 | 13 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -82.6±1.5 | 0 | 14 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +23±1.5 | 124.6 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | 0 | 101.6 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ15.7 | Φ273.05 | Φ228.6 | +38.1±1.5 | 139.7 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ15 | Φ273.1 | Φ230 | -4±1.5 | 93.6 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ15 | Φ273 | Φ230 | -4±1.5 | 95.1 | 10 | |
| 8.00V-20 | 3 Piece | 5H | Φ21.5 | Φ335 | Φ291 | +36±1.5 | 137.5 | 12 | |
| 8.00V-20 | 3 Piece | 12H | Φ26 | Φ381 | Φ325 | +137±1.5 | 238.6 | 14 | |
| 8.00V-20 | 3 Piece | 10H | Φ27 | Φ335 | Φ281 | +162±1.5 | 271 | 13 | |
| 8.00V-20 | 3 Piece | 8H | Φ22 | Φ275 | Φ221 | +15±1.5 | 124 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ20.6 | Φ203.2 | Φ152.4 | +38.1±1.5 | 139.7 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +4.5±1.5 | 106 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -84.5±1.5 | 13 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -82.6±1.5 | 0 | 14 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +23±1.5 | 124.6 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | 0 | 101.6 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ15.7 | Φ273.05 | Φ228.6 | +38.1±1.5 | 139.7 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ15 | Φ273.1 | Φ230 | -4±1.5 | 93.6 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ15 | Φ273 | Φ230 | -4±1.5 | 95.1 | 10 | |
| 8.00V-20 | 3 Piece | 5H | Φ21.5 | Φ335 | Φ291 | +36±1.5 | 137.5 | 12 | |
| 8.00V-20 | 3 Piece | 12H | Φ26 | Φ381 | Φ325 | +137±1.5 | 238.6 | 14 | |
| 8.00V-20 | 3 Piece | 10H | Φ27 | Φ335 | Φ281 | +162±1.5 | 271 | 13 | |
| 8.00V-20 | 3 Piece | 8H | Φ22 | Φ275 | Φ221 | +15±1.5 | 124 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ20.6 | Φ203.2 | Φ152.4 | +38.1±1.5 | 139.7 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +4.5±1.5 | 106 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -84.5±1.5 | 13 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | -82.6±1.5 | 0 | 14 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | +23±1.5 | 124.6 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ17.2 | Φ203.2 | Φ153 | 0 | 101.6 | 10 | |
| 8.00V-20 | 3 Piece | 8H | Φ15.7 | Φ273.05 | Φ228.6 | +38.1±1.5 | 139.7 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ15 | Φ273.1 | Φ230 | -4±1.5 | 93.6 | 12 | |
| 8.00V-20 | 3 Piece | 8H | Φ15 | Φ273 | Φ230 | -4±1.5 | 95.1 | 10 | |
| 8.00V-20 | 3 Piece | 5H | Φ21.5 | Φ335 | Φ291 | +36±1.5 | 137.5 | 12 | |
| 8.50-20 | 3 Piece | 10H | Φ20 | Φ335 | Φ281 | 0 | 109 | 16 | |
| 8.50-20 | 3 Piece | 10H | Φ20 | Φ335 | Φ281 | 0 | 109 | 16 | |
| 10.00-20 | 3 Piece | 20H | Φ26 | Φ335 | Φ281 | +152±1.5 | 274 | 12 | |
| 10.00-20 | 3 Piece | 20H | Φ26 | Φ335 | Φ281 | +152±1.5 | 274 | 12 | |
| 10.00-20 | 3 Piece | 20H | Φ26 | Φ335 | Φ281 | +152±1.5 | 274 | 12 | |
| 10.00-20 | 3 Piece | 20H | Φ26 | Φ335 | Φ281 | +152±1.5 | 274 | 12 | |
| 11.00T-20 | 3 Piece | 8H | Φ23.8 | Φ275 | Φ223.5 | +27±1.5 | 175 | 14 | |
| 11.00T-20 | 3 Piece | 8H | Φ22 | Φ275 | Φ221 | -39.7±1.5 | 115 | 10 | |
| 11.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +14.3±1.5 | 163 | 10 | |
| 11.00T-20 | 3 Piece | 6H | Φ21 | Φ180 | Φ133 | -12.7±1.5 | 113 | 14 | |
| 11.00T-20 | 3 Piece | 6H | Φ20 | Φ180 | Φ141 | -8.2±1.5 | 119.5 | 12 | |
| 11.00T-20 | 3 Piece | 6H | Φ20 | Φ180 | Φ141 | -28.1±1.5 | 108.6 | 12 | |
| 11.00T-20 | 3 Piece | 8H | Φ22 | Φ275 | Φ221 | -39.7±1.5 | 115 | 10 | |
| 11.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +14.3±1.5 | 163 | 10 | |
| 11.00T-20 | 3 Piece | 6H | Φ21 | Φ180 | Φ133 | -12.7±1.5 | 113 | 14 | |
| 11.00T-20 | 3 Piece | 8H | Φ23.8 | Φ275 | Φ223.5 | +27±1.5 | 175 | 14 | |
| 11.00T-20 | 3 Piece | 8H | Φ22 | Φ275 | Φ221 | -39.7±1.5 | 115 | 10 | |
| 11.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +14.3±1.5 | 163 | 10 | |
| 11.00T-20 | 3 Piece | 6H | Φ21 | Φ180 | Φ133 | -12.7±1.5 | 113 | 14 | |
| 11.00T-20 | 3 Piece | 6H | Φ20 | Φ180 | Φ141 | -8.2±1.5 | 119.5 | 12 | |
| 11.00T-20 | 3 Piece | 6H | Φ20 | Φ180 | Φ141 | -28.1±1.5 | 108.6 | 12 | |
| 11.00T-20 | 3 Piece | 8H | Φ23.8 | Φ275 | Φ223.5 | +27±1.5 | 175 | 14 | |
| 11.00T-20 | 3 Piece | 8H | Φ22 | Φ275 | Φ221 | -39.7±1.5 | 115 | 10 | |
| 11.00T-20 | 3 Piece | 8H | Φ17.5 | Φ203.2 | Φ153 | +14.3±1.5 | 163 | 10 | |
| 11.00T-20 | 3 Piece | 6H | Φ21 | Φ180 | Φ133 | -12.7±1.5 | 113 | 14 | |
| 11.00T-20 | 3 Piece | 6H | Φ20 | Φ180 | Φ141 | -8.2±1.5 | 119.5 | 12 | |
| 11.00T-20 | 3 Piece | 6H | Φ20 | Φ180 | Φ141 | -28.1±1.5 | 108.6 | 12 | |
| 12.00-20 | 3 Piece | 8H | Φ27 | Φ275 | Φ221 | 0 | 154.4 | 14 | |
| 12.00-20 | 3 Piece | 8H | Φ24 | Φ275 | Φ221 | -27.4±1.5 | 111 | 14 | |
| 12.00-20 | 3 Piece | 8H | Φ27 | Φ275 | Φ221 | 0 | 154.4 | 14 | |
| 12.00-20 | 3 Piece | 8H | Φ24 | Φ275 | Φ221 | -27.4±1.5 | 111 | 14 | |
| 12.00-20 | 3 Piece | 8H | Φ27 | Φ275 | Φ221 | 0 | 154.4 | 14 | |
| 12.00-20 | 3 Piece | 8H | Φ24 | Φ275 | Φ221 | -27.4±1.5 | 111 | 14 | |
| 12.00-20 | 3 Piece | 8H | Φ27 | Φ275 | Φ221 | 0 | 154.4 | 14 | |
| 12.00-20 | 3 Piece | 8H | Φ24 | Φ275 | Φ221 | -27.4±1.5 | 111 | 14 | |
| 8.50-24 | 3 Piece | 12H | Φ26 | Φ210 | Φ157.7 | -64.6±1.5 | 29.4 | 14 | |
| 8.50-24 | 3 Piece | 10H | Φ30.5 | Φ335 | Φ282.6 | -13.7±1.5 | 89.8 | 13.5 | |
| 8.50-24 | 3 Piece | 10H | Φ28.6 | Φ335 | Φ282.6 | -26.6±1.5 | 76.4 | 14 | |
| 8.50-24 | 3 Piece | 10H | Φ27 | Φ335 | Φ284 | +14±1.5 | 131 | 13 | |
| 8.50-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | -5.6±1.5 | 95.4 | 16 | |
| 8.50-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | -5.6±1.5 | 97.4 | 14 | |
| 8.50-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | -4±1.5 | 101 | 14 | |
| 8.50-24 | 3 Piece | 8H | Φ27 | Φ275 | Φ224 | +14±1.5 | 122 | 13 | |
| 8.50-24 | 3 Piece | 5H | Φ21.5 | Φ335 | Φ290 | 0 | 108 | 18 | |
| 8.50-24 | 3 Piece | 5H | Φ21 | Φ335 | Φ291 | +71.5±1.5 | 179.5 | 16 | |
| 8.50-24 | 3 Piece | 12H | Φ26 | Φ210 | Φ157.7 | -64.6±1.5 | 29.4 | 14 | |
| 8.50-24 | 3 Piece | 10H | Φ30.5 | Φ335 | Φ282.6 | -13.7±1.5 | 89.8 | 13.5 | |
| 8.50-24 | 3 Piece | 10H | Φ28.6 | Φ335 | Φ282.6 | -26.6±1.5 | 76.4 | 14 | |
| 8.50-24 | 3 Piece | 10H | Φ27 | Φ335 | Φ284 | +14±1.5 | 131 | 13 | |
| 8.50-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | -5.6±1.5 | 95.4 | 16 | |
| 8.50-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | -5.6±1.5 | 97.4 | 14 | |
| 8.50-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | -4±1.5 | 101 | 14 | |
| 8.50-24 | 3 Piece | 8H | Φ27 | Φ275 | Φ224 | +14±1.5 | 122 | 13 | |
| 8.50-24 | 3 Piece | 5H | Φ21.5 | Φ335 | Φ290 | 0 | 108 | 18 | |
| 8.50-24 | 3 Piece | 5H | Φ21 | Φ335 | Φ291 | +71.5±1.5 | 179.5 | 16 | |
| 8.50-24 | 3 Piece | 12H | Φ26 | Φ210 | Φ157.7 | -64.6±1.5 | 29.4 | 14 | |
| 8.50-24 | 3 Piece | 10H | Φ30.5 | Φ335 | Φ282.6 | -13.7±1.5 | 89.8 | 13.5 | |
| 8.50-24 | 3 Piece | 10H | Φ28.6 | Φ335 | Φ282.6 | -26.6±1.5 | 76.4 | 14 | |
| 8.50-24 | 3 Piece | 10H | Φ27 | Φ335 | Φ284 | +14±1.5 | 131 | 13 | |
| 8.50-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | -5.6±1.5 | 95.4 | 16 | |
| 8.50-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | -5.6±1.5 | 97.4 | 14 | |
| 8.50-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | -4±1.5 | 101 | 14 | |
| 8.50-24 | 3 Piece | 8H | Φ27 | Φ275 | Φ224 | +14±1.5 | 122 | 13 | |
| 8.50-24 | 3 Piece | 5H | Φ21.5 | Φ335 | Φ290 | 0 | 108 | 18 | |
| 8.50-24 | 3 Piece | 5H | Φ21 | Φ335 | Φ291 | +71.5±1.5 | 179.5 | 16 | |
| 10.00-24 | 3 Piece | 20H | Φ26 | Φ425 | Φ370 | +188±1.5 | 321 | 12 | |
| 10.00-24 | 3 Piece | 12H | Φ26 | Φ425 | Φ370 | +199±1.5 | 338 | 12 | |
| 10.00-24 | 3 Piece | 12H | Φ26 | Φ210 | Φ156.5 | -12.5±1.5 | 98.5 | 16 | |
| 10.00-24 | 3 Piece | 10H | Φ26 | Φ335 | Φ281 | -10±1.5 | 114 | 20 | |
| 10.00-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | - | - | 14 | |
| 10.00-24 | 3 Piece | 8H | Φ27 | Φ275 | Φ221 | +67.9±1.5 | 195 | 14 | |
| 10.00-24 | 3 Piece | 8H | Φ19 | Φ275 | Φ221 | -11±1.5 | 100 | 16 | |
| 10.00-24 | 3 Piece | 20H | Φ26 | Φ425 | Φ370 | +188±1.5 | 321 | 12 | |
| 10.00-24 | 3 Piece | 12H | Φ26 | Φ425 | Φ370 | +199±1.5 | 338 | 12 | |
| 10.00-24 | 3 Piece | 12H | Φ26 | Φ210 | Φ156.5 | -12.5±1.5 | 98.5 | 16 | |
| 10.00-24 | 3 Piece | 10H | Φ26 | Φ335 | Φ281 | -10±1.5 | 114 | 20 | |
| 10.00-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | - | - | 14 | |
| 10.00-24 | 3 Piece | 8H | Φ27 | Φ275 | Φ221 | +67.9±1.5 | 195 | 14 | |
| 10.00-24 | 3 Piece | 8H | Φ19 | Φ275 | Φ221 | -11±1.5 | 100 | 16 | |
| 10.00-24 | 3 Piece | 20H | Φ26 | Φ425 | Φ370 | +188±1.5 | 321 | 12 | |
| 10.00-24 | 3 Piece | 12H | Φ26 | Φ425 | Φ370 | +199±1.5 | 338 | 12 | |
| 10.00-24 | 3 Piece | 12H | Φ26 | Φ210 | Φ156.5 | -12.5±1.5 | 98.5 | 16 | |
| 10.00-24 | 3 Piece | 10H | Φ26 | Φ335 | Φ281 | -10±1.5 | 114 | 20 | |
| 10.00-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | - | - | 14 | |
| 10.00-24 | 3 Piece | 8H | Φ27 | Φ275 | Φ221 | +67.9±1.5 | 195 | 14 | |
| 10.00-24 | 3 Piece | 8H | Φ19 | Φ275 | Φ221 | -11±1.5 | 100 | 16 | |
| 10.00-24 | 3 Piece | 20H | Φ26 | Φ425 | Φ370 | +188±1.5 | 321 | 12 | |
| 10.00-24 | 3 Piece | 12H | Φ26 | Φ425 | Φ370 | +199±1.5 | 338 | 12 | |
| 10.00-24 | 3 Piece | 12H | Φ26 | Φ210 | Φ156.5 | -12.5±1.5 | 98.5 | 16 | |
| 10.00-24 | 3 Piece | 10H | Φ26 | Φ335 | Φ281 | -10±1.5 | 114 | 20 | |
| 10.00-24 | 3 Piece | 10H | Φ23.8 | Φ335 | Φ281 | - | - | 14 | |
| 10.00-24 | 3 Piece | 8H | Φ27 | Φ275 | Φ221 | +67.9±1.5 | 195 | 14 | |
| 10.00-24 | 3 Piece | 8H | Φ19 | Φ275 | Φ221 | -11±1.5 | 100 | 16 | |
| 12.00-24 | 3 Piece | 10H | Φ27 | Φ335 | Φ280 | -49±1.5 | 131.6 | 16 | |
| 12.00-24 | 3 Piece | 10H | Φ26 | Φ335 | Φ281 | 0 | 152.5 | 16 | |
| 12.00-24 | 3 Piece | 10H | Φ27 | Φ335 | Φ280 | -49±1.5 | 131.6 | 16 | |
| 12.00-24 | 3 Piece | 10H | Φ26 | Φ335 | Φ281 | 0 | 152.5 | 16 | |
| 12.00-24 | 3 Piece | 10H | Φ27 | Φ335 | Φ280 | -49±1.5 | 131.6 | 16 | |
| 12.00-24 | 3 Piece | 10H | Φ26 | Φ335 | Φ281 | 0 | 152.5 | 16 | |
| 11.25-25 | 3 Piece | 16H | Φ22 | Φ370 | Φ320 | 0 | 146.8 | 16.5 | |
| 11.25-25 | 3 Piece | 16H | Φ22 | Φ370 | Φ320 | 0 | 146.8 | 16.5 | |
| 11.25-25 | 3 Piece | 16H | Φ22 | Φ370 | Φ320 | 0 | 146.8 | 16.5 | |
| 14.00-25 | 3 Piece | 12H | Φ26.5 | Φ500 | Φ370 | 0 | 180 | 18 | |
| 14.00-25 | 3 Piece | 12H | Φ25 | Φ210 | Φ158 | -24±1.5 | 148 | 14 | |
| 14.00-25 | 3 Piece | 12H | Φ25 | Φ210 | Φ157.7 | -34±1.5 | 160 | 18 | |
| 14.00-25 | 3 Piece | 12H | Φ25 | Φ210 | Φ155 | -30.5±1.5 | 141.5 | 16 | |
| 2.50-8 | 2 Piece | 5H | Φ15 | Φ107.95 | Φ68 | 0 | 60.5 | 3 | |
| 2.50-8 | 2 Piece | 5H | Φ15 | Φ107.95 | Φ68 | 0 | 28.75 | 3 | |
| 2.50-8 | 2 Piece | 5H | Φ15 | Φ107.95 | Φ68 | 0 | 60.5 | 3 | |
| 2.50-8 | 2 Piece | 5H | Φ15 | Φ107.95 | Φ68 | 0 | 28.75 | 3 | |
| 3.00-8 | 2 Piece | 6H | Φ10.7 | Φ155 | Φ203.2 | 0 | - | 4 | |
| 3.00-8 | 2 Piece | 6H | Φ10.7 | Φ120 | Φ203.2 | 0 | - | 4 | |
| 3.00-8 | 2 Piece | 5H | Φ15 | Φ114.3 | Φ203.2 | 0 | - | 3.5 | |
| 3.00-8 | 2 Piece | 6H | Φ10.7 | Φ155 | Φ203.2 | 0 | - | 4 | |
| 3.00-8 | 2 Piece | 6H | Φ10.7 | Φ120 | Φ203.2 | 0 | - | 4 | |
| 3.00-8 | 2 Piece | 5H | Φ15 | Φ114.3 | Φ203.2 | 0 | - | 3.5 | |
| 4.33R-8 | 2 Piece | 8H | Φ15.7 | Φ141.93 | Φ106.8 | 0 | 74.8 | 5.5 | |
| 4.33R-8 | 2 Piece | 8H | Φ15.7 | Φ140 | Φ103.4 | -4.2±1.5 | 42 | 8.75 | |
| 22.00-25 | 5 Piece | 27H | Φ22 | Φ493 | Φ455 | +48.5±1.5 | 360 | 20 | |
| 4.33R-8 | 2 Piece | 6H | Φ18 | Φ140 | Φ100 | 0 | 33.5 | 3 | |
| 22.00-25 | 5 Piece | 26H | Φ26 | Φ485 | Φ429 | +275±1.5 | 554.5 | 33 | |
| 4.33R-8 | 2 Piece | 8H | Φ15.7 | Φ141.93 | Φ106.8 | 0 | 74.8 | 5.5 | |
| 22.00-25 | 5 Piece | 24H | Φ25 | Φ410 | Φ350 | -33±1.5 | 254 | 25 | |
| 4.33R-8 | 2 Piece | 8H | Φ15.7 | Φ140 | Φ103.4 | -4.2±1.5 | 42 | 8.75 | |
| 22.00-25 | 5 Piece | 20H | Φ25.5 | Φ425 | Φ370 | +30±1.5 | 325.5 | 23 | |
| 4.33R-8 | 2 Piece | 6H | Φ18 | Φ140 | Φ100 | 0 | 33.5 | 3 | |
| 22.00-25 | 5 Piece | 27H | Φ22 | Φ493 | Φ455 | +48.5±1.5 | 360 | 20 | |
| 4.00-9 | 2 Piece | 6H | Φ18 | Φ180 | Φ227.8 | 0 | - | 5.5 | |
| 22.00-25 | 5 Piece | 26H | Φ26 | Φ485 | Φ429 | +275±1.5 | 554.5 | 33 | |
| 5.00-10 | 2 Piece | 4H | Φ18 | Φ185 | Φ254 | 0 | - | - | |
| 22.00-25 | 5 Piece | 24H | Φ25 | Φ410 | Φ350 | -33±1.5 | 254 | 25 | |
| 3.75-12 | 2 Piece | - | - | - | Φ87.2 | 0 | 54.65 | 4 | |
| 22.00-25 | 5 Piece | 20H | Φ25.5 | Φ425 | Φ370 | +30±1.5 | 325.5 | 23 | |
| 4.00-12 | 2 Piece | 5H | Φ13.5 | Φ114.3 | Φ303.25 | 0 | - | 6 | |
| 25.00-25 | 5 Piece | 19H | Φ24 | Φ500 | Φ448 | +25±1.5 | 410 | 18 | |
| 5.00S-12 | 2 Piece | 6H | Φ15 | Φ152 | Φ118 | -12.7±1 | - | 10 | |
| 25.00-25 | 5 Piece | 19H | Φ24 | Φ500 | Φ448 | +25±1.5 | 410 | 18 | |
| 5.00S-12 | 2 Piece | 6H | Φ15 | Φ152 | Φ118 | -12.7±1 | - | 10 | |
| 28.00-33 | 5 Piece | 38H | Φ26 | Φ693 | Φ617 | +357±1.5 | 711 | 38 | |
| 5.00S-12 | 2 Piece | 6H | Φ15 | Φ152 | Φ118 | -12.7±1 | - | 10 | |
| 19.50-25 | 3 Piece | 10H | Φ27 | Φ480 | Φ420 | +3.5±1.5 | 263 | 18 | |
| 19.50-25 | 3 Piece | 16H | Φ25.5 | Φ480 | Φ430 | +182±1.5 | 470 | 16 | |
| 19.50-25 | 3 Piece | 19H | Φ25.4 | Φ500 | Φ450 | +30±1.5 | 290.5 | 18 | |
| 19.50-25 | 3 Piece | 20H | Φ24 | Φ425 | Φ371 | +97.5±1.5 | 345 | 20 | |
| 19.50-25 | 3 Piece | 20H | Φ26 | Φ310 | Φ261 | 0 | 248 | 25 | |
| 19.50-25 | 3 Piece | 20H | Φ26 | Φ310 | Φ262 | -6±1.5 | 228 | 25 | |
| 19.50-25 | 3 Piece | 20H | Φ26 | Φ310 | Φ263 | 0 | 280 | 22 | |
| 19.50-25 | 3 Piece | 20H | Φ26 | Φ420 | Φ371 | +90.5±1.5 | 373 | 20 | |
| 19.50-25 | 3 Piece | 10H | Φ27 | Φ480 | Φ420 | +3.5±1.5 | 263 | 18 | |
| 19.50-25 | 3 Piece | 16H | Φ25.5 | Φ480 | Φ430 | +182±1.5 | 470 | 16 | |
| 19.50-25 | 3 Piece | 19H | Φ25.4 | Φ500 | Φ450 | +30±1.5 | 290.5 | 18 | |
| 19.50-25 | 3 Piece | 20H | Φ24 | Φ425 | Φ371 | +97.5±1.5 | 345 | 20 | |
| 19.50-25 | 3 Piece | 20H | Φ26 | Φ310 | Φ261 | 0 | 248 | 25 | |
| 19.50-25 | 3 Piece | 20H | Φ26 | Φ310 | Φ262 | -6±1.5 | 228 | 25 | |
| 19.50-25 | 3 Piece | 20H | Φ26 | Φ310 | Φ263 | 0 | 280 | 22 | |
| 19.50-25 | 3 Piece | 20H | Φ26 | Φ420 | Φ371 | +90.5±1.5 | 373 | 20 | |
| 17.00-25 | 3 Piece | 12H | Φ23 | Φ425 | Φ508 | +26.4±1.5 | 250 | 9.5 | |
| 17.00-25 | 3 Piece | 19H | Φ26.5 | Φ500 | Φ448 | -22±1.5 | 187.9 | 18 | |
| 17.00-25 | 3 Piece | 12H | Φ23 | Φ425 | Φ508 | +26.4±1.5 | 250 | 9.5 | |
| 17.00-25 | 3 Piece | 19H | Φ26.5 | Φ500 | Φ448 | -22±1.5 | 187.9 | 18 | |
| 14.00-25 | 3 Piece | 12H | Φ22 | Φ404 | Φ352 | -21±1.5 | 152 | 15 | |
| 14.00-25 | 3 Piece | 12H | Φ24 | Φ404 | Φ352 | +13±1.5 | 191 | 14 | |
| 14.00-25 | 3 Piece | 12H | Φ25 | Φ210 | Φ155 | -30.5±1.5 | 141.5 | 16 | |
| 14.00-25 | 3 Piece | 12H | Φ25 | Φ210 | Φ157.7 | -34±1.5 | 160 | 18 | |
| 14.00-25 | 3 Piece | 12H | Φ25 | Φ210 | Φ158 | -24±1.5 | 148 | 14 | |
| 14.00-25 | 3 Piece | 12H | Φ26.5 | Φ500 | Φ370 | 0 | 180 | 18 | |
| 14.00-25 | 3 Piece | 12H | Φ22 | Φ404 | Φ352 | -21±1.5 | 152 | 15 | |
| 14.00-25 | 3 Piece | 12H | Φ24 | Φ404 | Φ352 | +13±1.5 | 191 | 14 |
